THE RAVEN QP

Vacuum/Pressure System

  • 460 CFM Efficient Continuous Duty Pump
  • 8 Vanes
  • Tamper Proof Oiler
  • 5-Year Warranty
  • Oil Catch Muffler
  • Flush Valve
  • Fan Cooled & Shrouded
  • Positive Primary and Secondary Shutoff
  • Clutch Shift PTO
  • Belt Driven from PTO
  • Electric Actuated
  • Over Speed Protection


Water Tank

  • Polished aluminum with ½” bottom and 5/16” heads. (Steel if requested)
  • Proprietary interior Firokote coating with two 9# anode bars
  • 15-year non-pro-rated corrosion (rust) perforation warranty, lifetime leak
  • Size ranging from 1500-3500+
  • Water level indicators
  • Patent-designed internal vent system specific for fire service
  • Patent-designed baffles with no flat surfaces to control inertial forces
  • Two full-length 7” wide skids (one on each side)
  • Interior reinforcing rings


Water Tank

  • Polished aluminum with ½” bottom and 5/16” heads. (Steel if requested)
  • Proprietary interior Firokote coating with two 9# anode bars
  • 15 year non pro-rated corrosion (rust) perforation warranty, lifetime leak
  • Size ranging from 1500-3500+
  • Water level indicators
  • Patent designed internal vent system specific for fire service
  • Patent designed baffles with no flat surfaces to control inertial forces
  • Two full length 7” wide skids (one each side)
  • Interior reinforcing rings


Water Valves

  • Driver and passenger side air-operated butterfly with positive closure and indicator.
  • Rear air-operated butterfly with positive closure and indicator.
  • Quick couple fittings.


Compartments

  • Two aluminum in front of the rear wheels (polished or painted)
  • Open hose tray the length of the unit on each side



Compartments

  • Two aluminum in front of the rear wheels (polished or painted)
  • Open hose tray the length of the unit on each side



Drop Tank Bracket

  • Manual Fold Down
  • Zico Power Fold Down- Single Capacity
  • Firovac Power Fold Down- Double Capacity


Other Features

  • PTO-driven fire pump of the desired size.
  • Cross Lays and Cross Lay Storage.
  • "Pump and Roll" capabilities.
  • Lettering, Striping, Chevron.
  • Loose goods, hoses, patented Floating Low-Flow Strainer with detachable pan
  • The only performance guarantee on the market today!
  • NFPA compliant
  • Many more options available!


Other Features

  • PTO driven fire pump of desired size with pump and roll capabilities
  • Cross lays
  • "Pump and Roll"
  • Lettering, striping
  • Loose goods, hoses, patented floating low flow strainer with detachable pan
  • The only performance guarantee on the market today
  • NFPA compliant
  • Many options


Firovac™ Trucks are Truly Made by Firefighters for Firefighters!
